Technical specification
Bicycle
Model year
2022
Frame
19″ Aluminium
Fork
SunTour CR8V ( travel:63 mm)
Wheel
STARS, 28 in, three-chambered hoops
Tires
Wanda 28 x 1.75
Spoke
SAPIM 13G / Front wheel: 288 mm / Rear wheel: 247 mm
Front hub
Joytech 751DSE
Handlebar
PROMAX HB-T320 ( 25,4mm / 600mm )
Handlebar stem
PROMAX MQ-525
Grip
VELO VLG－519AD2
Brakes
Promax TX117
Shifters
Shimano Altus – 7 gears
Grip
Revoshift Shimano SL-RS35-7R
Freewheel
Skiful FW-207B/BK / 7sp / 14-28T
Bottom bracket
Feimin FP-B902W (68*124mm) BSA
Chain
KMC z7
Crank
PROWHEEL PRO-A42 / 42T / 170 mm
Pedals
WELLGO
Saddle
Selle Royal Lookin Basic-A230
Seat post
27.2 mm / 350 mm
Front lights
Spaninga KENDO XE
Rear light
Spaninga RL1900XE
Weight
22,2 kg (aluminium)
Steerer parameters
zew. 28.6 mm / wew. 25.4 mm / dł.180 mm
Battery
Charger
220－240 W / 42V / 2A / D type
Smart BMS
Yes
Cells brand
LG / Greenway
Capacity Wh
468 – 576 Wh
Type
Li-ion
Voltage
36 V
Range
80 – 130 km
Fuses
30 A
Lifespan
700 charges
Charging time
6 – 8 hours
Capacity ah
11.6 Ah
E-bike system
Motor
BAFANG
Type
rear wheel
Voltage
36 V
Torque
45 N.m
Power
250 W
Computer
SO-WZK0148-D
Speed
35 km / h limited to 25 km / h in accordance with EU standard EN 15194
GARANCIJA 12 MESECI
