Technical specification
Bicycle
Stem
Promax MQ-525
Frame
19″ hydroformed aluminum
Fork
Steel
Wheel
28 “Sapim three-chamber reinforced spokes
Tires
28″ x 1.75 Impac StreetPac
Front hub
Joytech 751DSE
Rear Hub
not applicable
Handlebar
Promax 600 mm 25.4
Grip
Velo VLG 519AD2
Brakes
Promax TX－117 V-brakes
Shifters
Shimano Tourney 6 speed
Grip
Shimano Tourney Revo 6 speed
Freewheel
Shimano MF-TZ500 14-28T 6 speed
Bottom bracket
Feimin FP-B902W
Chain
KMC
Crank
Prowheel 42T
Pedals
VP
Saddle
Aifeit
Seat post
Promax 27.2 / 350 mm
Seat post
Promax 105 mm
Front lights
Spaninga HL1900XE 36V E-BIKE
Rear light
Spaninga RL1900XE DC36V E-BIKE
Maximum load
125 kg
Weight
21,1 kg
Battery
Internal resistance
???
Max charging current
2.35 A
Smart BMS
Yes
Max charging voltage
36 V
Working temperature
-10 – 40°C
Cells brand
LG / Greenway
Capacity Wh
313,2 – 630 Wh
Type
Li-ion
Voltage
36 V
Range
60 – 140 km
Lifespan
700 cycles
Charging time
4-8 hours
Capacity ah
8.7-17.5 Ah
E-bike system
Motor
XOFO
Model
SOFD-135
Type
Rear hub
Voltage
36 V
Torque
32 N.m
Maximum power
320 W
Power
250 W
Speed
25 km/h in accordance with EU standard EN 15194
Display
Number of support levels
3
Display model
792-36L
Display brand
Kingmeter
Display type
LED display
Speed indicator
No
Mileage information
Nie
“Walk assist” function
Tak
Waterproof connector
Yes
GARANCIJA 12 MESECI
