| E-SYSTEM | BOSCH PT-CX7R4 |
|---|---|
| FRAME | Macina Lycan 27.5″ Alloy6061 SLL-E 140mm; PT750 Bosch Gen.4 / M-2296 |
| FORK | Suntour XCR 34 Air 27.5″ LOR 140mm 15×110 taper |
| SHOCK | RockShox Deluxe Select+ 230×62.5 |
| MOTOR | Bosch PERFORMANCE CX Gen.4 SMART SYSTEM – 25km/h / 85Nm |
| DISPLAY | Bosch LED remote SMART SYSTEM |
| BATTERY | Bosch PowerTUBE 750Wh SMART SYSTEM hor. |
| CHARGER | Bosch STANDARD Charger 4A SMART SYSTEM |
| R. DERAILL | Shimano Deore M5100-11 SGS shadow+ |
| SHIFTLEV. | Shimano Deore M5100-11 |
| CRANKSET | KTM E-TRAIL ISIS 170mm Q16 |
| CHAINRING | FSA steel 36T Direct Mount |
| SPROCKET | Shimano Deore M5100-11 / 11-51 |
| CHAIN | KMC e11 Sport EPT e-bike |
| BRAKE | Tektro HD-M750 / E730 4-Piston |
|---|---|
| ROTOR | Tektro TR-45 2.3mm CL 203 / 180 |
| WHEEL F | KTM Line – Shimano MT410B CL 32H 110-15TA / Ambrosio E30 Trail 32H 584x30TC / DT Champion 2.0 black |
| WHEEL R | KTM Line – Shimano MT400B CL 32H 148-12TA / Ambrosio E30 Trail 32H 584x30TC / DT Alpine II 2.34 black |
| TIRE F | Schwalbe Nobby Nic Perf. Folding 65-584 |
| TIRE R | Schwalbe Nobby Nic Perf. Folding 65-584 |
| GRIP | KTM Comp Lock |
| BAR | KTM COMP II Trail35 rizer15 760mm |
| STEM | KTM TEAM II Trail35 |
| HEADSET | Acros AICR internal 1.1/8″-1.5″ angle limit |
| SADDLE | KTM Line Sport |
| SEATPOST | KTM COMP II dropper internal |
| PEDAL | MTB-Pedal flat VPE-527 alloy |
| WEIGHT | 26,30 kg |
| PERMISSIBLE TOTAL WEIGHT | 145 kg |
