| E-SYSTEM | BOSCH SI-A4P2 |
|---|---|
| FRAME | Macina Trekk. Offroad US Alloy6061; Si-PP500Wh Bosch Gen.3 / T-2730 |
| FORK | Suntour NEX-E25 coil NLO 63mm |
| MOTOR | Bosch ACTIVE Gen.3 – 25km/h / 40Nm |
| DISPLAY | Bosch PURION LCD Display |
| BATTERY | Bosch PowerPACK 400Wh |
| CHARGER | Bosch COMPACT Charger 2A |
| R. DERAILL | Shimano Altus M2000-9 SGS shadow |
| SHIFTLEV. | Shimano Alivio M3100-9 display |
| CRANKSET | KTM LINE BNI 170mm Q16 |
| CHAINRING | FSA steel 40T Direct Mount with Chainguard |
| SPROCKET | Shimano HG201-9 / 11-36 |
| CHAIN | Shimano HG53-9 |
| BRAKE | Shimano MT200 / MT200 2-Piston |
| ROTOR | Shimano RT30 CL 180 / EM300 CL 160 |
|---|---|
| WHEEL F | KTM Line – Shimano MT200 CL 32H 100-5QR / Ryde Eco21 32H 622x21C / DT Champion 2.0 silver |
| WHEEL R | KTM Line – Shimano Acera M3050 CL 32H 135-5QR / Ryde Eco21 32H 622x21C / DT Alpine II 2.34 silver |
| TIRE F | Schwalbe Smart Sam K-Guard 42-622 |
| TIRE R | Schwalbe Smart Sam K-Guard 42-622 |
| GRIP | KTM Comp Ergo Lock |
| BAR | KTM Line rizer15 640mm |
| STEM | KTM Line 17° |
| HEADSET | Ritchey OE Zero Logic 1.1/8″ |
| SADDLE | Selle Royal Rio+ |
| SEATPOST | KTM Comp 30.9/350 |
| PEDAL | MTB-Pedal VPE-891 steel |
| WEIGHT | 21,4 kg |
| PERMISSIBLE TOTAL WEIGHT | 122 kg |
